In this tutorial, the Simulation pullout behavior of a silicon carbide (ceramic) nail from the bone in Abaqus has been investigated with two interaction methods. The ceramic nail or screw is a three-dimensional solid part. The bone is modeled as a three-dimensional solid part. Because of the part’s difficulties, they ...

In this tutorial, the Simulation rigid projectile impact to the ceramic-CFRP panel in Abaqus-Damage investigation – has been done. The rigid projectile is modeled as a three-dimensional shell part. The ceramic is modeled as a three-dimensional thick solid part. The CFRP or carbon fiber is modeled as a three-dimensional shell ...

In this tutorial, the Simulation oblique high-velocity impact of an aluminum rod to the silicon-carbide target in Abaqus has been investigated. The silicon-carbide target is modeled as a three-dimensional solid part. The aluminum projectile is modeled as a three-dimensional solid part. You can see a figure of the assembled parts ...

In this tutorial, the Simulation cutting process of the silicon carbide(ceramic) material by using a rigid body in Abaqus has been investigated. The silicon carbide is modeled as a three-dimensional solid part. The cutting tool is modeled as a three-dimensional solid part. You can see a figure of the assembled ...

In this tutorial, Simulation High-velocity impact of a brass projectile on the Ceramic-Aluminum-Glass fiber in Abaqus has been investigated. The brass projectile, the ceramic plate, aluminum plate, and epoxy-glass layers are modeled as three-dimensional parts. You can see a figure of the assembled parts at below The brass material is ...

In this tutorial Simulation steel-Silicon Carbide-Steel trilayers subject to ballistic impact in Abaqus has been studied.Armor systems containing ceramic components can significantly outperform monolithic metals of equivalent areal density. Their performance depends on not only the intrinsic properties of the constituent materials but also on the relative amounts of ceramic ...

In this tutorial simulation blast resistance of sandwich structure(Ceramic-Foam-Aluminum) in Abaqus has been investigated.As a result of their low weight and superior flexural properties, sandwich structures, based on strong, stiff skins bonded to low density cores are finding increasing use in a wide range of engineering structures. In a bid ...

In this tutorial Prediction model of depth of penetration for alumina ceramics under garnet impact in Abaqus has been studied .The target and projectile were modeled as three dimensional parts .The JH-2 constitutive model was proposed to describe the response of ceramic materials to large strain rate. The JH-2 constitutive model ...

The study of interaction between two impacting bodies, known as impact dynamics or terminal ballistics has many crucial applications. Bullet impact on armor, occupant and pedestrian safety during automobile accidents, tool drop on aircraft wing, are few examples where impact dynamics plays an important role. An in-depth understanding of deformation ...
