بایگانی برچسب: crack

Abaqus Crack growth Package- A lecture contains 10 tutorials – More than five hours of simulation

In this lecture through ten step-by-step tutorials, many aspects of the crack growth like XFEMm H integral, and … in concrete, steel, dam, bone, and…are investigated. All the tutorials are explained from A to Z, each tutorial contains cae, inp, and step-by-step English video. All the tutorials in the package ...

ادامه نوشته »

Crack growth simulation of bone under three points bending in Abaqus

In this tutorial crack growth simulation of bone under three points bending in Abaqus has been studied. Structural analysis of bones is now actively studied by many researchers using the finite-element method (FEM) to better understand the mechanism of bone fractures. Most previous studies, however, only obtained distribution patterns of stress or ...

ادامه نوشته »

Simulation crack growth in concrete containing wood shavings as aggregates in Abaqus

The critical mechanical characteristics governing the usability of concrete containing wood shavings as aggregates are mechanical strength and durability.There is a renewed interest in the use of wood-based composite materials because of their ability to regulate indoor climate. Numerous studies have shown that the hygroscopic behavior of materials of vegetable ...

ادامه نوشته »

Simulation crack growth in the Koyna dam under seismic load in Abaqus

In this example we consider an analysis of the Koyna dam, which was subjected to an earthquake of magnitude 6.5 on the Richter scale on December 11, 1967. The example illustrates a typical application of the concrete damage base on traction separation laws. Dam is modeled as two dimensional part ...

ادامه نوشته »

Simulation three dimensional crack growth in concrete slab by using XFEM technique

In this video Simulation three dimensional crack growth in concrete slab by using XFEM technique in Abaqus software has been studied.Concrete part is modeled as three dimensional part with traction separation behavior which defined in material property. To model crack growth under static load XFEM procedure with planar crack has been ...

ادامه نوشته »

Crack modeling and mechanical fracture parameter in the four point bending test in Abaqus

 In this tutorial crack modeling and mechanical fracture parameter in the four point bending test in Abaqus has been investigate. Piece has a crack edge with three mm length which under the bending load. In this example two dimensional part has been used and the pieces is modeled with steel material ...

ادامه نوشته »

Simulation crack growth in the concrete by using XFEM procedure

In this video XFEM crack growth in the two Dimensional concrete palate in Abaqus has been simulated. Concrete is modeled as 2D shell element and Separation Traction Low appropriate with crack growth has been used. Dynamic Implicit step is performed and you can see some figures of this simulation at ...

ادامه نوشته »

Simulation XFEM crack growth of a pressure vessel in ABAQUS

In this video XFEM crack growth in the pressure vessel has been simulated. Pressure vessel geometry imported to Abaqus from Solidworks because of difficulties to modeling it in Abaqus. Aluminum material for pressure vessel with traction separation laws(Maxps) mix with power law evolution to predict crack growth has been used. ...

ادامه نوشته »

Simulation ellipsoid crack in the pressure vessel under variable pressure with subroutine

In this video you can see step by step tutorial of ellipsoid crack in the pressure vessel under internal and external pressure in ABAQUS sofware.The internal pressure is fixed but the external pressure is variable with time and location. For calculation the external pressure we used DLOAD subroutine as function ...

ادامه نوشته »

شبیه سازی رشد ترک در یک نمونه CT شکل به روش XFEM در آباکوس

در این ویدئو به شبیه سازی قدم به قدم رشد ترک در یک نمونه CT شکل به روش XFEM در نرم افزار آباکوس پرداخته ایم. برای ماده قطعه از یک نوع کمپوزیت همراه با معیار مناسب برای پیش بینی شکست المان ها برای رشد ترک و مشاهده نمود فیزیکی آن ...

ادامه نوشته »
