خانه / بایگانی برچسب: abaqus (صفحه 10)

بایگانی برچسب: abaqus

شبیه سازی تست فشار دو لوله فولادی ۸ ضلعی با هسته بتنی در نرم افزار آباکوس

در این ویدئو به شبیه سازی تست فشار دو لوله فولادی ۸ ضلعی با هسته بتنی در نرم افزار آباکوس پرداخته ایم. مدل شامل دو لوله فولادی ۸ ضلعی به صورت پارت شل و یک پارت بتنی سالید می باشد. مدلسازی ها در اسکچ به طور کامل توضیح داده شده ...

ادامه نوشته »

Simulation Crashworthiness behavior of aluminum profiles with holes considering damage criteria and damage evolution

In this tutorial, Simulation Crashworthiness behavior of aluminum profiles with holes considering damage criteria and damage evolution has been studied. Recently, the use of thin-walled structures in automobiles to increase the safety and integrity of passengers during car collisions, have gained importance by automotive manufacturers and designers. An important characteristic ...

ادامه نوشته »

شبیه سازی مچالگی پروفیل آلومینیومی تحت با فشاری با استفاده از معیارهای آسیب در آباکوس

در این ویدئوی آموزشی به شبیه سازی مچالگی پروفیل آلومینیومی تحت با فشاری با استفاده از معیارهای آسیب در نرم افزار آباکوس پرداخته ایم. مدل سازی به صورت سه بعدی بوده و پروفیل آلومینیومی با استفاده از یک پارت شل سه بعدی و صفحه صلب در نقش جسم وارد کننده ...

ادامه نوشته »

Simulation CEL explosion over the composite foam-insulated concrete sandwich panels in Abaqus

In this tutorial, the Simulation CEL explosion over the composite foam-insulated concrete sandwich panels in Abaqus has been studied. Two concrete layers at the front and back are modeled as a three-dimensional solid part. The foam inside those two layers is modeled as a three-dimensional part and the beam as ...

ادامه نوشته »

شبیه سازی انفجار به روش کوپل اویلری-لاگرانژی روی یک پنل بتنی سه لایه با هسته فومی در آباکوس

در این ویدئو به شبیه سازی انفجار به روش کوپل اویلری-لاگرانژی روی یک پنل بتنی سه لایه با هسته فومی در نرم افزار آباکوس پرداخته ایم. مدل شامل دو قطعه بتنی سه بعدی و سالید به همراه یک قطعه فومی در میانه آنها می باشد. در هر دو قطعه بتنی ...

ادامه نوشته »

Crushing Simulation of Foam-Filled Aluminium Tubes in Abaqus

In this simulation, Crushing Simulation of Foam-Filled Aluminium Tubes in Abaqus has been studied. Thin-walled metallic tubes have been applied as energy absorbers because of their progressive buckling under axial compressive loading and the lightness of the structure. According to previous investigations, thin-walled circular tubes can collapse in axisymmetric mode, also ...

ادامه نوشته »

Numerical simulation of blast resistance of RC slab strengthened with AFRP in Abaqus-Damage investigation

In this tutorial, numerical simulation of blast resistance of RC slab strengthened with AFRP in Abaqus-Damage investigation- has been studied. The concrete slab is modeled as a three-dimensional solid part, the AFRP is modeled as four layers composite with shell part and the embedded beam inside the concrete host is ...

ادامه نوشته »

شبیه سازی انفجار در هوا روی یک قطعه بتنی تقویت شده با الیاف AFRP در نرم افزار آباکوس- بررسی آسیب

در این ویدئو به شبیه سازی انفجار در هوا روی یک قطعه بتنی تقویت شده با الیاف AFRP در نرم افزار آباکوس- بررسی آسیب- پرداخته ایم. مدل بتن به صورت سه بعدی و سالید، میلگردها به صورت پارت وایر سه بعدی و ورق کامپوزیتی از جنس الیاف آرامید به صورت ...

ادامه نوشته »

Simulation cyclic loading of the reduce beam section-column with stiffener in Abaqus

In this tutorial, Simulation cyclic loading of the reduce beam section-column with a stiffener in Abaqus has been investigated. The RBS part is modeled as a three-dimensional shell part, the box column, and the stiffener is modeled as three-dimensional shell parts. You can see a figure of the assembled parts ...

ادامه نوشته »

شبیه سازی بارگذاری سیکلی روی یک تیر با مقطع کاهش یافته متصل به ستون به همراه اتصال جوشی در آباکوس

در این ویدئو به شبیه سازی بارگذاری سیکلی روی یک تیر با مقطع کاهش یافته متصل به ستون به همراه اتصال جوشی در نرم افزار آباکوس پرداخته ایم.تیر به صورت سه بعدی و با استفاده از مدل شل ،ستون به صورت قوطی و مدل شل و همچنین سخت کننده یا ...

ادامه نوشته »

Simulation composite column (steel beam and concrete) under cyclic loading in Abaqus

In this tutorial, the simulation composite column(steel beam and concrete)under cyclic loading in Abaqus has been studied. The steel beam and the concrete parts are modeled as three-dimensional solid parts. You can see a figure of the assembled parts at below The steel material is used for the steel beam ...

ادامه نوشته »

شبیه سازی بارگذاری تکراری روی یک ستون مرکب بتنی-فولادی در نرم افزار آباکوس

در این ویدئو به شبیه سازی بارگذاری تکراری روی یک ستون مرکب بتنی-فولادی در نرم افزار آباکوس پرداخته ایم. مدلسازی به صورت سه بعدی بوده و از دو پارت سه بعدی و تغییر شکلپذیر بتن و تیر فولادی تشکیل شده است. در شکل زیر می توانید نحوه قرارگیری اجزا در ...

ادامه نوشته »

Simulation High velocity impact of a brass projectile on the Ceramic-Aluminum-Glass fiber in Abaqus

In this tutorial, Simulation High-velocity impact of a brass projectile on the Ceramic-Aluminum-Glass fiber in Abaqus has been investigated. The brass projectile, the ceramic plate, aluminum plate, and epoxy-glass layers are modeled as three-dimensional parts. You can see a figure of the assembled parts at below The brass material is ...

ادامه نوشته »

شبیه سازی برخورد پرتابه سرعت بالای برنجی به ورق چندلایه سرامیکی-آلمینیومی-کامپوزیتی در نرم افزار آباکوس

در این ویدئو آموزشی به شبیه سازی برخورد پرتابه سرعت بالای برنجی به ورق چندلایه سرامیکی-آلمینیومی-کامپوزیتی در نرم افزار آباکوس پرداخته ایم. تمامی اجزا شامل پرتابه،ورق سرامیکی،ورق آلمینیومی و چهار لایه کامپوزیت به صورت سه بعدی و تغییر شکلپذیر ترسیم شده اند. در شکل زیر می توانید نحوه قرارگیری اجزا ...

ادامه نوشته »

Simulation steel beam-column connection with bolt in Abaqus-Beam failure investigation

In this tutorial, the Simulation steel beam-column connection with bolt-in Abaqus under vertical load-Beam failure investigation- has been studied. The beam with endplate is modeled as a three-dimensional solid part, the column is modeled as a three-dimensional solid part and the ten bolts are modeled as three-dimensional solid parts. You ...

ادامه نوشته »

شبیه سازی اتصال تیر به ستون فولادی با پیچ و بررسی پارگی ورق تیر تحت اثر جابه جایی عمودی در آباکوس

در این ویدئو به شبیه سازی اتصال تیر به ستون فولادی با پیچ و بررسی پارگی ورق تیر تحت اثر جابه جایی عمودی در نرم افزار آباکوس پرداخته ایم. مدلسازی به صورت سه بعدی بوده و تیر به همراه ورق انتهایی جوش شده به صورت سه بعدی و سالید، مجموعا ...

ادامه نوشته »

Simulation Sequential Construction of an Embankment on a Clay Layer in Abaqus

In this tutorial Simulation, Sequential Construction of an Embankment on a Clay Layer in Abaqus has been investigated. The two-dimensional part is used for modeling the clay layer and three layers of the embankment. You can see a figure of the assembling part ate below Each embankment layer is constructed ...

ادامه نوشته »

شبیه سازی احداث مرحله ای خاکریز بر روی یک لایه خاک رس در نرم افزار آباکوس

در این ویدئو به شبیه سازی احداث مرحله ای خاکریز بر روی یک لایه خاک رس در نرم افزار آباکوس پرداخته ایم. مدلسازی به صورت دوبعدی بوده، خاک رس و سه لایه خاکریز همگی در یک پارت ترسیم و به وسیله پارتیشن بندی به نواحی مورد نظر تقسیم شده اند. ...

ادامه نوشته »

Simulation steel beam-column connection with steel angle under cyclic loading in Abaqus

In this tutorial Simulation steel beam-column connection with steel angle under cyclic loading in Abaqus has been investigated. The beam and column are modeled as three-dimensional shell parts and the steel angle is modeled as a three-dimensional shell part. You can see a figure of the assembled parts at below ...

ادامه نوشته »

شبیه سازی اتصال تیر به ستون فولادی به همراه نبشی جوش شده تحت بارگذاری سیکلی در آباکوس-بررسی آسیب

در این ویدئو به شبیه سازی اتصال تیر به ستون فولادی به همراه نبشی جوش شده تحت بارگذاری سیکلی در آباکوس-بررسی آسیب- پرداخته ایم. مدلسازی به صورت سه بعدی بوده،تیر و ستون فولادی به صورت شل و نبشی به صورت پارت شل سه بعدی طراحی شده اند. در شکل زیر ...

ادامه نوشته »

Bolt failure simulation on the steel beam and column connection in Abaqus

In this tutorial Bolt failure simulation on the steel beam and column connection in Abaqus has been investigated. The bolts, steel beam, and column are modeled as three-dimensional parts. You can see a figure of the assembled parts at below The steel structure is an assemblage of different members such ...

ادامه نوشته »

شبیه سازی اتصال پیچی تیر به ستون و بررسی پارگی پیچ ها تحت بار عمودی در نرم افزار آباکوس

در این ویدئو به شبیه سازی اتصال پیچی تیر به ستون و بررسی پارگی پیچ ها تحت بار عمودی در نرم افزار آباکوس پرداخته ایم. مدل شامل سه پارت سه بعدی تغییر شکل پذیر تیر فولادی،ستون و مجموعا ده پیچ می باشد که در شکل زیر می توانید نحوه قرارگیری ...

ادامه نوشته »

Simulation infill masonry wall in two steel column under vertical and transverse load in Abaqus

In this tutorial, Simulation infill masonry wall in two steel column under vertical and transverse load in Abaqus has been studied. Masonry structures are among the most common types of buildings, being economical and easily made. The possibility of using conventional materials, the easy method of construction and the lower ...

ادامه نوشته »

شبیه سازی دیوار بنایی در میان دو ستون فلزی تحت بار فشاری و عرضی در نرم افزار آباکوس-میکرو مدل

در این ویدئو به شبیه سازی دیوار بنایی در میان دو ستون فلزی تحت بار فشاری و عرضی در نرم افزار آباکوس-میکرو مدل- پرداخته ایم. مدل شامل آجرهای سالم و نصفه به صورت سه بعدی، دو تیر بتنی سه بعدی در بالا و پایین دیوار و دو تیر فولادی در ...

ادامه نوشته »

Simulation cyclic loading over a steel column with stiffeners in Abaqus-Damage investigation

In this tutorial, Simulation cyclic loading over a steel column with stiffeners in Abaqus-Damage investigation- has been studied. The box column is modeled as a three-dimensional shell part and the stiffener is modeled as a planar shell part. You can see a figure of assembled part at below The stiffeners ...

ادامه نوشته »

شبیه سازی بارگذاری سیکلی روی یک ستون فلزی به همراه سخت کننده در نرم افزار آباکوس-بررسی پارامتر آسیب

در این ویدئو به شبیه سازی بارگذاری سیکلی روی یک ستون فلزی به همراه سخت کننده در نرم افزار آباکوس-بررسی پارامتر آسیب- پرداخته ایم. مدلسازی به صورت سه بعدی بوده و ستون فلزی به صورت قوطی وشل ترسیم شده است. سخت کننده ها نیز در پایه تیر به صورت شل ...

ادامه نوشته »

Simulation reinforced concrete beam with FRP under four points bending in Abaqus

In this tutorial, Simulation reinforced concrete beam with FRP under four points bending in Abaqus has been studied. The concrete beam is modeled as three dimensional part, the FRP is modeled as a conventional shell with tow layouts with different rotation angle. You can see a figure of the assembled ...

ادامه نوشته »

شبیه سازی خمش چهار نقطه ای تیر بتنی تقویت شده با اف آر پی در نرم افزار آباکوس-بررسی آسیب

در این ویدئو به شبیه سازی خمش چهار نقطه ای تیر بتنی تقویت شده با اف آر پی در نرم افزار آباکوس-بررسی آسیب- پرداخته ایم. تیر بتنی به صورت سه بعدی طراحی شده و ورق اف آر پی یا همان کامپوزیت به صورت شل ترسیم شده است. ورق کامپوزیتی مقاوم ...

ادامه نوشته »

Simulation underwater explosion near a concrete dam by using the CEL method in Abaqus

In this tutorial Simulation underwater explosion near a concrete dam by using the CEL method in Abaqus has been investigated. The dam is modeled as a three dimensional part, The TNT, water, and air are modeled as the Eulerian part. You can see a figure of the assembled parts at ...

ادامه نوشته »

شبیه سازی انفجار به روش اویلری لاگرانژی در نزدیکی یک سد بتنی در آباکوس-انفجار زیر آب

در این ویدئو به شبیه سازی انفجار به روش اویلری لاگرانژی در نزدیکی یک سد بتنی در آباکوس-انفجار زیر آب- پرداخته ایم. مدلسازی به صورت سه بعدی بوده و سد به صورت جسم تغییر شکلپذیر ترسیم شده است. ماده منفجره،هوا و آب نیز به صورت پارت اویلری سه بعدی ایجاد ...

ادامه نوشته »

Simulation steel pipe reinforcement with CFRP layouts in Abaqus under three points bending

In this tutorial Simulation steel pipe reinforcement with CFRP layouts in Abaqus under three points bending has been studied. Circular hollow section (CHS) are widely used in many applications but predominantly used as pipelines in the oil and gas industry. Natural resources like oil and gas constitute the major share ...

ادامه نوشته »

شبیه سازی خمش سه نقطه ای لوله فولادی تقویت شده با ورق CFRP چند لایه در نرم افزار آباکوس

در این ویدئو به شبیه سازی خمش سه نقطه ای لوله فولادی تقویت شده با ورق CFRP چند لایه در نرم افزار آباکوس پرداخته ایم. مدلسازی به صورت سه بعدی بوده و برای لوله فولادی و کامپوزیت از دو پارت شل و برای مدلسازی تکیه گاه ها و جک هیدرولیک ...

ادامه نوشته »

Simulation of concrete cover separation failure in FRP plated RC beam in Abaqus

In this tutorial Simulation of concrete cover separation failure in FRP plated RC beam in Abaqus has been studied.The infrastructures in developed countries are aging and in addition changes in their using purposes, increase of load level, constructional faults and damages or deterioration demand adequate maintenance and the upgrading of ...

ادامه نوشته »

شبیه سازی تیر بتنی تقویت شده با FRP و چسب تحت خمش سه نقطه ای در آباکوس-بررسی جدایش FRP

در این ویدئو به شبیه سازی تیر بتنی تقویت شده با FRP و چسب تحت خمش سه نقطه ای در نرم افزار آباکوس-بررسی جدایش FRP- پرداخته ایم.تیر بتنی به صورت سه بعدی و تغییر شکل پذیر،لایه چسب به صورت سه بعدی،FRP به صورت شل سه بعدی و تیکه گاه ها ...

ادامه نوشته »

Masonry wall behavior under couple Eulerian-Lagrangian explosion in Abaqus

In this tutorial Masonry wall behavior under couple Eulerian-Lagrangian explosion in Abaqus has been simulated.Numerical simulations are used extensively for solving a vast variety of dynamic problems associated with explosions, such as gaseous or condensed charge detonations followed by pressure wave propagation through the ambient air. Utilizing these methods, it ...

ادامه نوشته »

شبیه سازی انفجار به روش کوپل اویلری لاگرانژی در نزدیکی دیوار بنایی در آباکوس-بررسی تخریب

در این ویدئو به شبیه سازی انفجار به روش کوپل اویلری لاگرانژی در نزدیکی دیوار بنایی در آباکوس-بررسی تخریب- پرداخته ایم. دیوار آجری به صورت پارت سالید ایجاد شده که آجر های افقی و عمودی در محیط اسمبلی مونتاژ شده اند. محیط پیرامون دیوار به صورت اویلری در نظر گرفته ...

ادامه نوشته »

Simulation rigid body rotation model for predicting a response of soil-filled wall subjected to blast in Abaqus

In this tutorial Simulation rigid body rotation model for predicting a response of soil-filled wall subjected to blast in Abaqus has been done.Steel tank is modeled as a three dimensional shell part,domain is modeled as Eulerian part and soil as a solid part inside the domain. You can see a ...

ادامه نوشته »

شبیه سازی انفجار روی یک مخزن فولادی حاوی خاک در نرم افزار آباکوس

در این ویدئو به شبیه سازی انفجار روی یک مخزن فولادی حاوی خاک در نرم افزار آباکوس پرداخته ایم. هندسه مخزن به صورت پارت سه بعدی از نوع شل بوده، محیط به صورت پارت اویلری و خاک نیز به صورت پارت سالید در فضای اویلری تعریف شده است. نحوه قرارگیری ...

ادامه نوشته »

Simulation Eulerian-Lagrangian explosion in the stone tunnel in interaction with soil in Abaqus

In this tutorial Simulation Eulerian-Lagrangian explosion in the stone tunnel in interaction with soil in Abaqus has been studied.The stone tunnel is modeled as three dimensional solid part, the TNT and soil is modeled as volume inside the Eulerian domain. You can see a figure of the assembled parts at ...

ادامه نوشته »

شبیه سازی انفجار به روش اویلری لاگرانژی داخل تونل سنگی در تعامل با خاک در نرم افزار آباکوس

در این ویدئو به شبیه سازی انفجار به روش اویلری لاگرانژی داخل تونل سنگی در تعامل با خاک در نرم افزار آباکوس پرداخته ایم. تونل به صورت سه بعدی و تغییر شکل پذیر،محیط پخش موج انفجار به صورت اویلری،تی ان تی و خاک در همین محیط به صورت سه بعدی ...

ادامه نوشته »

Finite element simulation of air blast explosion over the glass in Abaqus-Damage analysis

In this tutorial Finite element simulation of air blast explosion over the glass in Abaqus-Damage analysis- has been investigated.The glass and frame are modeled as a three dimensional part.You can see a figure of the assembled parts at below Elastic plastic material with Johnson-Cook damage criterion is used to model ...

ادامه نوشته »

شبیه سازی انفجار در هوا روی یک سازه شیشه ای در نرم افزار آباکوس-بررسی پارامتر آسیب

در این ویدئو به شبیه سازی انفجار در هوا روی یک  سازه شیشه ای در نرم افزار آباکوس-بررسی پارامتر آسیب- پرداخته ایم. مدل شیشه به صورت سه بعدی  تغییر شکل پذیر و قاب فلزی اطراف شیشه نیز به صورت سه بعدی ترسیم شده اند. در شکل زیر می توانید نحوه ...

ادامه نوشته »

Simulation ballistic impact of steel projectile to the soda-lime glass in Abaqus-Damage investigation

In this tutorial Simulation ballistic impact of steel projectile to the soda-lime glass in Abaqus-Damage investigation has been studied. Glass is a very complex material, whose modelling presents a significant challenge.Glass is very compressible and experiences densification that increases with time, temperature, pressure, and applied shear. It was demonstrated that ...

ادامه نوشته »

شبیه سازی برخورد پرتابه فولادی سرعت بالا به ورق ضخیم شیشه ای در نرم افزار آباکوس-بررسی پارامتر آسیب

در این ویدئو به شبیه سازی برخورد پرتابه فولادی سرعت بالا به ورق ضخیم شیشه ای در نرم افزار آباکوس-بررسی پارامتر آسیب- پرداخته ایم. مدلسازی به صورت سه بعدی بوده و هر دو پارت شیشه و پرتابه به صورت جسم سالید تغییر شکل پذیر ترسیم شده اند. در شکل زیر ...

ادامه نوشته »

Dynamic analysis of tunnel in soil subjected to internal blast loading by using CEL method in Abaqus

In this tutorial Dynamic analysis of tunnel in soil subjected to internal blast loading by using CEL method in Abaqus has been investigated. The concrete tunnel is model as solid part,domain as a Eulerian part,TNT and soil as solid part and beam as wire part. You can see some figures ...

ادامه نوشته »

شبیه سازی انفجار به روش کوپل اویلری لاگرانژی داخل تونل بتنی تقویت شده در عمق خاک در نرم افزار آباکوس

در این ویدئو به شبیه سازی انفجار به روش کوپل اویلری لاگرانژی داخل تونل بتنی تقویت شده در عمق خاک در نرم افزار آباکوس پرداخته ایم. مدلسازی به صورت سه بعدی بوده که در آن تونل بتنی به صورت پارت سالید،فضای انتشار ماده منفجره به صورت پارت اویلری و میلگردها ...

ادامه نوشته »

Simulation tapered concrete steel column subjected axial loading in Abaqus

In this tutorial Simulation tapered concrete steel column subjected axial loading in Abaqus has been studied.The concrete core is modeled as three dimensional part and steel is modeled as a three dimensional shell part. Two rigid boundary conditions and loading point in Abaqus.You can see a figure of the assembled ...

ادامه نوشته »

شبیه سازی ستون بتنی هرمی شکل با روکش فلزی تحت بار محوری فشاری در نرم افزار آباکوس

در این ویدئو به شبیه سازی ستون بتنی هرمی شکل با روکش فلزی تحت بار محوری فشاری در نرم افزار آباکوس پرداخته ایم. مدلسازی به صورت سه بعدی بوده و ستون بتنی به صورت تغییر شکل پذیر و سالید ترسیم شده است. ستون فلزی بیرونی با استفاده از پارت شل ...

ادامه نوشته »

Simulation Couple Eulerian Lagrangian explosion over RC column with steel beam core in Abaqus

In this tutorial Simulation Couple Eulerian Lagrangian explosion over RC column with steel beam core in Abaqus has been studied. The concrete column and steel beam are modeled as three dimensional part,the domain is modeled as eulerian part with TNT and the bars are modeled as three dimensional wire part ...

ادامه نوشته »

شبیه سازی انفجار به روش اویلری لاگرانژی روی یک ستون بتنی تقویت شده با هسته تیر فولادی در آباکوس

در این ویدئو به شبیه سازی انفجار به روش اویلری لاگرانژی روی یک ستون بتنی تقویت شده با هسته تیر فولادی در نرم افزار آباکوس پرداخته ایم. مدلسازی به صورت سه بعدی بوده که در آن تیر بتنی به صورت پارت سالید، تیر فولادی به صورت پارت سالید،بازه مکانی انفجار ...

ادامه نوشته »
